Front
A
ADF (Automatic Document Feeder) cover
(F)
Open when removing jammed originals in the ADF.
B
ADF edge guides Feeds originals straight into the printer. Slide to the edges of the
originals.
C
ADF input tray Feeds originals automatically.
D
ADF output tray Holds originals ejected from the ADF.
E
Control panel Allows you to make settings and perform operations on the printer.
Also displays the printer's status.
F
Paper cassette 1 or Paper cassette (C1) Loads paper.
G
Paper cassette 2 (C2) Optional paper cassette unit. Loads paper. You can install up to 3
paper cassette units.
H
Paper cassette 3 (C3)
I
Paper cassette 4 (C4)
J
External interface USB port Connects memory devices.
Part Names and Functions
>
Front
22
