Rear
A
LAN port Connects a LAN cable.
B
USB port Connects a USB cable to connect with a computer.
C
Service USB port USB port for future use. Do not remove the sticker.
D
LINE port Connects a phone line.
E
EXT. port Connects external phone devices.
F
AC inlet Connects the power cord.
G
Rear cover (D) Open when replacing the pickup roller or removing jammed paper.
H
Rear cover (E) Open when replacing the pickup roller or removing jammed paper.
I
Maintenance box cover (H) Open when replacing the maintenance box. The maintenance box is
a container that collects a very small amount of surplus ink during
cleaning or printing.
