Epson WF-C5890 Series

To Next Page

To Previous Page

Inside

Document cover Blocks external light while scanning.

Scanner glass Place the originals. You can place originals that are not fed from the

ADF such as envelopes or thick books.

Part Names and Functions

Inside
