10. Secure the ink tray by attaching the supplied protective material with tape so that the tray can not open.

11. Close the ink cover.

12.

Uninstall the optional paper cassette unit if it is installed.

13. Prepare to pack the printer as shown below.

In These Situations

Transporting and Storing the Printer

289
