5.2 Function Codes Table
5-5
FUNCTION CODES
Chap 5
Code
Name Data setting range
Change when running
Data copying
Factory
Default
Drive control
Related page
V/f
PG V/f
w/ PG
Torque control
PM
F14
Restart mode after momentary
power failure (Mode selection)
0: Trip immediately
1: Trip after a recovery from power failure
2: Trip after momentary deceleration is stopped
3: Continue to run (for heavy inertia load or general load)
4: Restart from frequency at power failure (for general
load)
5: Restart from starting frequency
Y
Y
EU: 0
ACJK:1
Y
Y
Y
N
Y
5-66
F15
Frequency limiter (Upper limit)
0.0 to 500.0Hz
Y
Y
70.0
Y
Y
Y
N
Y
5-73
F16
(Lower limit)
0.0 to 500.0Hz
Y
Y
0.0
Y
Y
Y
N
Y
F18
Bias (for frequency setting 1)
-100.00 to 100.00%
Y*
Y
0.00
Y
Y
Y
N
Y
5-73
F20
DC braking 1
(Braking starting frequency)
0.0 to 60.0Hz
Y
Y
0.0
Y
Y
Y
N
Y
5-74
F21
(Braking level)
0 to 100% (HHD mode), 0 to 80% (HD/HND mode) 0 to 60%
(ND mode )
Y
Y
0
Y
Y
Y
N
Y
F22
(Braking time)
0.00 (Disable): 0.01 to 30.00 s
Y
Y
0.00
Y
Y
Y
N
Y
F23
Starting frequency 1
0.0 to 60.0Hz
Y
Y
0.5
Y
Y
Y
N
Y
5-77
F24
(Holding time)
0.00 to 10.00 s
Y
Y
0.00
Y
Y
Y
N
Y
F25
Stop frequency
0.0 to 60.0 Hz
Y
Y
0.2
Y
Y
Y
N
Y
F26
Motor sound
(Carrier frequency)
ND mode
- 0.75 to 10 kHz (FRN0002 to 0059E2

-4

)
- 0.75 to 6 kHz (FRN0072E2

-4

or above)
HD/HND mode
- 0.75 to16 kHz (FRN0001 to 0088E2

-2

)
- 0.75 to16 kHz (FRN0002 to 0059E2

-4

)
- 0.75 to16 kHz (FRN0001 to 0012E2

-7

)
- 0.75 to10 kHz (FRN0072 to 0168E2

-4

)
- 0.75 to10 kHz (FRN0115E2

-2

)
- 0.75 to 6 kHz (FRN0203E2

-4

or above)
HHD mode
- 0.75 to16 kHz (FRN0001 to 0115E2

-2

)
- 0.75 to16 kHz (FRN0002 to 0168E2

-4

)
- 0.75 to16 kHz (FRN0001 to 0012E2

-7

)
- 0.75 to10 kHz (FRN0203E2

-4

or above)
Y
Y
2
Y
Y
Y
Y
Y
5-80
F27
(Tone)
0: Level 0 (Disable)
1 to 3 : Level 1 to 3
Y
Y
0
Y
Y
N
N
N
F29
Terminal FM (Mode selection)
0: Voltage output (0 to +10 VDC)
1: Current output (4 to 20 mA DC)
2: Current output (0 to 20 mA DC)
3: Pulse output
Y
Y
0
Y
Y
Y
Y
Y
5-81
F30
(Output gain)
0 to 300%
Y*
Y
100
Y
Y
Y
Y
Y
F31
(Function selection)
0: Output frequency 1 (before slip compensation)
1: Output frequency 2 (after slip compensation)
2: Output current
3: Output voltage
4: Output torque
5: Load factor
6: Input power
7: PID feedback value
8: Actual speed/estimated speed *5
9: DC link bus voltage
10: Universal AO
13: Motor output
14: Calibration (+)
15: PID command (SV)
16: PID output (MV)
17: Position error in master-follower operation *5
18: Inverter heat sink temperature
21: PG feedback value *5
111 to 120 Customizable logic output signal 1 to 10
Y
Y
0
Y
Y
Y
N
Y
F32
Terminal FM 2 *1
(Mode selection)
0: Voltage output (0 to +10 VDC)
1: Current output (4 to 20 mA DC)
2: Current output (0 to 20 mA DC)
Y Y 0 Y Y Y Y Y
F33
Terminal FM (Pulse rate)
25 to 32000 p/s
(number of pulse at monitor value 100%)
Y* Y 1440 Y Y Y Y Y
F34
Terminal FM 2 *1
(Output gain)
0 to 300%
Y* Y 100 Y Y Y Y Y
F35
(Function selection)
Same as F31
Y
Y
2
Y
Y
Y
N
Y
Factory default

A (For Asia), C (for China), E (for Europe), U (For USA), J (for Japan), K (for Korea)
indicates quick setup target function code.
*1: F34 and F35 only exist for GB model and C model (for China).
*5: Available at ROM version 0300 or later.
