Appendix G Conformity with Standards
Appendix-27
Table G-2 EMC-compliant filter
Power supply voltage Inverter type Specification Filter type
Three-phase 400V
FRN0004E2■-4 ND/HD/HND/HHD W62400−T1688−E002 *1)
FRN0007E2■-4 ND/HD/HHD W62400−T1688−F002 *1)
FRN0012E2■-4 ND/HD/HHD W62400−T1688−F002 *1)
FRN0022E2■-4
ND FS21312-44-07
HHD FS21559-24-07-01
FRN0029E2■-4
HD/HND FS21312-44-07
HHD FS21559-24-07-01
FRN0037E2■-4
ND FS5536-72-07 (EFL-22G11-4)
HHD FS21312-44-07
FRN0044E2■-4
FS5536-72-07 (EFL-22G11-4)
HD/HND FS5536-72-07 (EFL-22G11-4)
HHD FS21312-44-07
FRN0059E2■-4
ND FS21312-78-07
FS5536-72-07 (EFL-22G11-4)
HHD FS5536-72-07 (EFL-22G11-4)
FRN0072E2■-4
HD/HND FS21312-78-07
HHD FS5536-72-07 (EFL-22G11-4)
FRN0085E2■-4
ND FS5536-180-40
HHD FS5536-100-35
FRN0105E2■-4
HD/HND FS5536-180-40
HHD FS5536-100-35
FRN0139E2■-4 ND/HD/HND/HHD FS5536-180-40
FRN0203E2■-4
ND FS5536-250-99-1
FRN0240E2■-4
ND FS5536-250-99-1
HD/HND FS5536-250-99-1
HHD FS5536-180-40
FRN0290E2■-4
FRN0361E2■-4
ND FS5536-400-99-1
HD/HND FS5536-400-99-1
HHD FS5536-250-99-1
FRN0520E2■-4 ND/HD/HND/HHD FS5536-400-99-1
FRN0590E2■-4
HD/HND FN3359-600-99 *2)
HHD FS5536-400-99-1
*1) A ferrite core is added for input power wires and grounding wire (2 turns), or two ferrite cores are added for
input power wires and grounding wire, 1 turns.
*2) IF carrier frequency setting is 4 kHz or less or a zero-phase reactor is added at the input cable, conforms
category C2. Except this condition, conforms category C3.
Note: A box (■) in the above table replaces S (Basic type) or E (EMC filter built-in type) depending on the
enclosure. A box () in the above table replaces GA, GB or C depending on the model.
