Connectivity & Network Setup
159
Tools
5
Important • Do not use the numbers assigned to the other ports.
îš„LPD - Maximum Number of Sessions
Enter the maximum number of sessions. You can enter a number between 1 and 10 in 1
session increments.
The default value is 5.
NetWare
îš„Port Status
Select [Enabled] to use NetWare.
SMB
îš„Port Status
Select [Enabled] to use SMB when using Scan to PC (SMB) service or sharing the machine
on the network.
IPP
îš„Port Status
Select [Enabled] to use IPP.
Set this when you want to use IPP (Internet Printing Protocol) to print via the Internet.
îš„IPP - Added Port Number
Enter the port number for IPP except the standard port number in the range from 1 to 65535.
To disable this option, enter "0".
The default value is 80.
Important • Do not use the numbers assigned to the other ports.
Note • You cannot select [IPP - Added Port Number], if IPP port is disabled.
Enable IPP port first and reboot the machine, and then configure [IPP - Added Port Number].
EtherTalk
îš„EtherTalk - Port Status
Select [Enabled] to use EtherTalk.
Bonjour
îš„Bonjour - Port Status
Select [Enabled] to use Bonjour.
Note • Bonjour can be set only when optional Adobe PostScript 3 Kit is installed.
• In order to print from a printer detected by [Bonjour], the LPD port must be activated in
advance.
Port 9100
îš„Port Status
Select [Enabled] to use Port9100.
Select this option when the communication protocol is in RAW format for Windows Standard
TCP/IP port monitor.
îš„Port 9100 - Port Number
Select [Standard (9100)] or [Enter Number].
Enter a port number in the range from 1 to 65535 when selecting [Enter Number].
The default value is 9100.
Important • Do not use the numbers assigned to the other ports.
