Replacing Consumables
63
Maintenance
3
6
Hold the staple cartridge by the orange lever,
and insert it into the finisher until it clicks.
7
Close the front cover of the finisher.
Note • If the front cover of the finisher is not completely closed, a message will appear and the
machine will not operate.
Replacing the Staple Cartridge (for Booklet Maker Unit for Finisher-B1)
When the Booklet Maker Unit for Finisher-B1 (optional) is installed and it is time to
replace the staple cartridge, a message appears on the touch screen. When this
message appears, load a new staple case into the staple cartridge.
Important • The use of staple cartridges not recommended by Fuji Xerox may impair quality and
performance. Use only staple cartridges recommended by Fuji Xerox for the machine.
Note • To order a staple cartridge, contact our Customer Support Center.
1
Make sure that the machine is not operating,
and open the side cover of the finisher.
2
Hold the tabs on both sides of the staple
cartridge and pull the cartridge out of the
finisher.
3
Hold the tabs on both sides of a new staple
cartridge, and insert it into the original posi-
tion until it clicks.
Note • If you have trouble inserting the cartridge,
make sure that the staples in the cartridge
are properly in place.
4
Repeat Steps 2 and 3 to replace the other
staple cartridge.
5
Close the side cover of the finisher.
Note • If the front cover of the finisher is not completely closed, a message will appear and the
machine will not operate.
To Next Page
