Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Removing the defective heat sink
▶
Remove the heat sink, see "Removing the standard heat sink" on page 231
or "Removing the performance heat sink" on page 232.
▶
Remove the residual thermal paste from the CPU surface.
▶
Clean the CPU surface using a lint-free cloth.
Installing the new heat sink
▶
Remove the protective cover on the underside of the new heat sink.
CAUTION
▶
Do not touch the thermal paste on the underside of the heat sink.
▶
Install the heat sink, see "Installing the standard heat sink" on page
239
or
"Installing the performance heat sink" on page 242.
Concluding steps
▶
"Reassembling" on page 54.
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
▶
"Performing a fan test" on page 100.
Processor (CPU)
244 Upgrade and Maintenance Manual TX1320 M5
