GAMATRONIC ELECTRONIC INDUSTRIES LTD.
84
POWER
+
SA: 20, 30, and 40 kVA, Release 2.1
9.9.3 Setting Module/s Voltage
1. Select Module/s voltage:
[Main Menu > SETUP > (password) > Module conf.]
1. Num of phase 5.Output Adjust
2. Module/s frequency 6.Frequency Limits
3. Module/s voltage 7.DC Calibration
4. Update Vo/Fr/ph 8.AC Calibration
Figure 139: Module Config. setup menu
2. Use the ▲▼arrow keys to set the module/s voltage, press Ent, and then Esc:
[Main Menu > SETUP > (password) > Module conf. > Module/s voltage]
Module/s voltage 4: 235V
1: 220V 5: 240V
2: 225V 6: 250V
3: 230V (selected) 5: 260V
Figure 140: Setting the Module/s voltage
9.9.4 Update Voltage/Frequency/Phase
1. Select Update Vo/Fr/ph:
[Main Menu > SETUP > (password) > Module conf.]
1. Num of phase 5.Output Adjust
2. Module/s frequency 6.Frequency Limits
3. Module/s voltage 7.DC Calibration
4. Update Vo/Fr/ph 8.AC Calibration
Figure 141: Module Config. setup menu
2. Press Ent to update, and then Esc:
[Main Menu > SETUP > (password) > Module conf. > Update Vo/Fr/ph]
Nominal Voltage & Frequency
have been sent to all modules.
Please verify all modules were updated!
Exit this mode by pressing Esc.
Figure 142: Updating the Module/s voltage/frequency/phase
