6. View the system jumper settings without remote panel:
[Main Menu > SYSTEM > ▼ ▼ ▼]
JMP: JMP1, JMP2, JMP3, JMP6 and JMP9
=IN 1. NOT HARD SILICON
2. SILICON MODE 6. NO RMT PAN.
12369 3. CAPACITY LOW 9. AC: 230V
Figure 83: Jumper settings WITHOUT remote panel
7. View the system jumper settings with remote panel:
[Main Menu > SYSTEM > ▼ ▼ ▼]
JMP: JMP1, JMP2, JMP3, JMP6 and JMP9
=IN 1. NOT HARD SILICON
2. SILICON MODE 6. Remote pan.
12369 3. CAPACITY LOW 9. AC: 230V
Figure 84: Jumper settings WITH remote panel
Note: In Figure 83 and Figure 84, “Silicon mode” indicates that the configuration jumper is
installed, thus allowing for modifications. “Hard Silicon” indicates that the factory
defaults hard reset jumper is installed. This is required only at the factory or whenever
software reset fails. Refer to section 9.15.9.3 for a detailed description of jumpers.
8. View the internal controller voltages:
[Main Menu > SYSTEM > ▼ ▼ ▼ ▼]
5VDC : 5.19V CONTROLLER INTERNAL
12VDC: 12.01V VOLTAGES
5VP : GOOD
5V2 : GOOD -12VDC: GOOD
Figure 85: Internal controller voltages
9. View battery parameters:
[Main Menu > SYSTEM > ▼ ▼ ▼ ▼ ▼]
BATTERY CHARGE LEVEL: 010Ah 050%
WHILE TOTAL CAPACITY: 020Ah
REMAINING BACKUP: 0010 MINUTES
BATTERY TEMPERATURE: 12°C
Figure 86: Battery parameters
Note: The data displayed in Figure 86 depends on the options installed and configured. See
Figure 152 on page 87 and Figure 188 on page 98.
