GAMATRONIC ELECTRONIC INDUSTRIES LTD.
40
POWER
+
SA: 20, 30, and 40 kVA, Release 2.1
6.7.2 Check Total Ampere-Hours
This procedure is designed to ensure that the total capacity of the batteries attached to
Power+ SA matches the definition of the total capacity in the System Controller.
1. Check the total capacity of the installed batteries attached to Power+ SA.
2. Verify that the same value is specified in the System Controller. If not, modify the
definition in the System Controller to match the capacity of the installed batteries.
To check the capacity defined in the System Controller:
1. From the Main Menu select option 5, Battery.
[Main Menu > BATTERY]
Battery capacity: 0020Ah
Charge mode : Floating
Eq. running time: --------
Charge current : 053.0A
Figure 40: Battery status
The battery status panel displays the battery capacity defined in the System Controller.
To set the battery capacity in the System Controller to a different value:
1. Note the current value of battery capacity:
[Main Menu > BATTERY > ▼> ▼> ▼> ▼> ▼]
1> Battery#1: 020 Ah Total Cap.: 0020 Ah
Figure 41: Battery capacity
2. Adjust the battery capacity to correspond to that of the attached batteries, and press
Ent:
[Main Menu > SETUP > (password) > Battery > Capacity 0020AH) > Set Capacity of Battery
#1]
Battery #01 Capacity setup
10 -990
Capacity :020 Ah
Figure 42: Set battery capacity
3. Repeat step 1 above to verify the set battery capacity.
