Gamatronic power+ sa - Figure 201: Set Date and Time; Figure 202: Setup Menu; Figure 203: Set Site Number; Setting the Site Number

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
POWER
+
SA: 20, 30 and 40 kVA, Release 2.1
103
2. Using the arrow keys, set the date and time, and then press Ent:
[Main Menu > SETUP > (password) > Time]
Set real time
Year Month Day Hour Min Sec
2011 09 30 23 58 00
Figure 201: Set date and time
9.11.3 Setting the Site Number
1. Select Site:
[Main Menu > SETUP > (password) > Ent]
1> Alarm set 5> Time 9> Silicon
2> Module conf. 6> Site
3> Battery 7> Password #1
4> Charge 8> Service
Figure 202: Setup menu
2. Use the arrow keys to set the site number, and then press Ent:
[Main Menu > SETUP > (password) > Site]
Site number: 013271
Figure 203: Set site number
Note: The serial number of Power+ SA is on a bar-code label at the bottom of the unit, on
the left hand side.
