GAMATRONIC ELECTRONIC INDUSTRIES LTD.
38
+
SA: 20, 30, and 40 kVA, Release 2.1
6.7 Configuration
Perform the following configuration steps from the Control Panel.
6.7.1 Check Configured Modules
Verify that the number of configured modules matches the desired output power, and verify
that the number of redundant modules is correct. Modify as needed.
1. Press Ent to reach the Main Menu.
1> SYSTEM 4> HISTORY 7> SETUP
2> UPS MODULE 5> BATTERY 8> STATIC SW
3> SELFTEST 6> ALARM 9> _____
NAVIGATE: <UP, DOWN> 1 SELECT: <ENTER>
Figure 33: Main Menu
2. From the Main Menu select option 7, Setup.
[Main Menu > SETUP]
POWER+ System Setup
Type in Level-1 PASSWORD, THEN – ENTER
Your privilege will expire after 15 min.
PASSWORD:________
Figure 34: Password access
3. When the Password access panel appears, enter the password and press Ent. The
factory default password is to press the key 8 times.
Note: If the password has been changed and the system does not accept it, request from
your system administrator the technician password, which cannot be changed, and
use it to reset the user password.
4. Select Service, option 8:
[Main Menu > SETUP > (password) > Ent]
1> Alarm set 5> Time 9> Silicon
2> Module conf. 6> Site
3> Battery 7> Password #1
4> Charge 8> Service
Figure 35: Setup menu
