7. Use the arrow keys to set BAT-HI, press Ent, and then Esc:
[Main Menu > SETUP > (password) > ALARM SET > FLOAT VOLT > BAT-HI]
FLOATING CHARGE ALARM SETUP
VOLTAGE SETTING: 475.0V
Figure 125: Set BAT-HI
9.8.3 Setting Battery Over/Under Temperature Alarms
1. Select TEMPERATURE:
[Main Menu > SETUP > (password) > ALARM SET]
1> AC VOLT 5> --------- 9>INTEGRAT.
2> FLOAT VOLT 6> ---------
3> --------- 7> TEMPERATURE
4> --------- 8> ---------
Figure 126: Alarm set menu
2. Select OVER TEMPERATURE:
[Main Menu > SETUP > (password) > ALARM SET > Temperature]
1> OVER TEMPERATURE
2> UNDER TEMPERATURE
PLEASE SELECT
Figure 127: Over/Under temperature menu
3. Use the arrow keys to set the battery maximum temperature alarm value and press
Ent:
[Main Menu > SETUP > (password) > ALARM SET > Temperature > OVER
TEMPERATURE]
SET OVER TEMPERATURE ALARM VALUE
( 2 – 99) DEGREES
45
Figure 128: Set battery maximum temperature alarm
