6. View battery capacity:

[Main Menu > BATTERY > ▼> ▼> ▼> ▼> ▼]

1> Battery#1: 020 Ah Total Cap.: 0020 Ah

Figure 105: Battery capacity

Note: Figure 103, Figure 104, and Figure 105 show the individual batteries on the left and

the overall total on the right. In the examples shown above, only one battery is

installed.

7. View battery (charging) current limit:

[Main Menu > BATTERY > ▼> ▼> ▼> ▼> ▼> ▼]

1> Battery#1: Current limit: 53A

Figure 106: Battery current limit
