9.10.6 Setting Disable Temperature Compensation
1. Select Temp Compensat.:
[Main Menu > SETUP > (password) > Battery]
1> Test-Voltage 5> Battery test…
2> Test Alarm 6> Capacity 0020 AH)
3> Current-Limit.. 7> ‘AuTo’ Test
4> Temp Compensat. 8> Enable/Dis Options
Figure 172: Battery setup menu
2. Select Enable Temp. Compensation and press Ent to toggle enable/disable:
[Main Menu > SETUP > (password) > Battery > Temp.Compensat.]
1> Temperature Compensation Value Setup
2> Enable Temp. Compensation ( OFF)
3> Set ABSOLUTE Max & Min Voltages 1
Press ‘2’ to toggle enable / disable
1> Temperature Compensation Value Setup
2> Disable Temp. Compensation (2.0 mV)
3> Set ABSOLUTE Max & Min Voltages 1
Press ‘2’ to toggle enable / disable
Figure 173: Enable/Disable temperature compensation
9.10.7 Setting Absolute Maximum and Minimum Voltages
1. Select Set ABSOLUTE Max & Min Voltages:
[Main Menu > SETUP > (password) > Battery > Temp. Compensat.]
1> Temperature Compensation Value Setup
2> Enable Temp. Compensation ( OFF)
3> Set ABSOLUTE Max & Min Voltages 1
Press ‘2’ to toggle enable / disable
Figure 174: Select Set ABSOLUTE Max & Min Voltages
