9.10.8 Activating the Battery Test
1. Select Battery test…:
[Main Menu > SETUP > (password) > Battery]
1> Test-Voltage 5> Battery test…
2> Test Alarm 6> Capacity 0020 AH)
3> Current-Limit.. 7> ‘AuTo’ Test
4> Temp Compensat. 8> Enable/Dis Options
Figure 179: Battery setup menu
2. Select Activate Battery Test… and press Ent:
[Main Menu > SETUP > (password) > Battery > Battery test…]
1> Activate battery test…
2> Set auto battery test period
3> Set auto battery test top time
1
Figure 180: Select Activate Battery Test…
3. Press Ent to start/stop test, and then press Esc:
[Main Menu > SETUP > (password) > Battery > Battery test…]
Max/estim. Time left: 05:27:00 /--:--:--
Battery test in progress for: 00:00:00
Batt. volt: 864V Batt. Current: ---
Press ‘Enter’ to start.
Figure 181: Activate battery test
9.10.9 Setting the Automatic Battery Test Period
1. Select Battery test…:
[Main Menu > SETUP > (password) > Battery]
1> Test-Voltage 5> Battery test…
2> Test Alarm 6> Capacity 0020 AH)
3> Current-Limit.. 7> ‘AuTo’ Test
4> Temp Compensat. 8> Enable/Dis Options
Figure 182: Battery setup menu
