4.3 Installation Procedure
After completing each step in the following installation, go back to the Installation Checklist
and check the corresponding item.
The
POWER+ SA is currently available in two different models and configurations. The
following installation instructions cover all models and configurations. Whenever procedures
differ, the model and configuration for which the procedure is applicable is clearly indicated.
If no such indication is present, the procedure applies to all models and configurations.
4.3.1 Visual Inspection
Perform the inspection described below immediately after unpacking the POWER+ SA.
1. Inspect the P
OWER+ SA from all sides and ensure that there is no visible damage to
any portion of the housings or covers.
2. Ascertain that the number of housings and modules corresponds to specifications.
3. Ensure that all components and modules are complete and securely fastened to
their shelves.
4.3.2 Site Preparation – Physical
Perform the following procedures before connecting any external cables to POWER+ SA.
1. Ensure that the ambient temperature in the immediate vicinity of P
OWER+ SA
complies with the following requirements.
Min/Max operating temperature: –10 °C and +40 °C (+14 °F and +104 °F).
Recommended temperature: +15 °C and +25 °C (+59 °F and +77 °F).
2. Verify that there is no water condensation or dampness at the installation site.
3. Ensure that sufficient airflow or forced ventilation is present at the location of the
battery cabinets.
4. Verify that the foundation and access routes are adequate for the dimensions and
weight of the UPS and battery cabinets.
5. Ensure that there are adequate clearances to allow comfortable access to battery
cabinets and electrical boards. Ensure that there is 91 cm (36 in.) clearance at the
rear for cable connections and 100 cm (39 in.) at front for user access and service.
4.3.3 Site Preparation – Electrical
Perform the following procedures before connecting any external cables to POWER+ SA.
1. Verify that circuit breakers on the electrical board that supplies P
OWER+ SA comply
with local code and Gamatronic system specifications. See Table 5 and Table 6.
2. Verify that the input and output power cable connections, GND, and neutral lines
comply with local and international codes and are appropriate for the circuit breakers
protecting them.
