GAMATRONIC ELECTRONIC INDUSTRIES LTD.
POWER
+
SA: 20, 30 and 40 kVA, Release 2.1
71
2. View next automatic equalizing, remaining equalizing time, total rectifier current, and
battery (charging) current:
[Main Menu > BATTERY > ▼]
Next automatic equalizing: 02 days
Remaining equalizing time: ___ minutes
Rectifiers total current : 0050A
Battery current : 053.0A
Figure 101: Battery equalizing
3. View the maximum estimated time left, battery test in progress time, battery voltage,
battery (charging) current, last test result, and days left:
[Main Menu > BATTERY > ▼ > ▼]
Max/estim time left : 00:00:00 /--:--:--
Battery test in progress for: 00:00:00
Batt. volt: 860.0V Batt.current: 008
Last test: PASSED Days left: 027
Figure 102: Time left
4. View battery status and status of the last test:
[Main Menu > BATTERY > ▼ > ▼ > ▼]
1> Battery#1: PASSED Last test: PASSED
Figure 103: Last test
5. View battery (charging) current:
[Main Menu > BATTERY > ▼ > ▼ > ▼ > ▼]
Batt1 curr: 052.1A Batt curr: 052.1A
Figure 104: Battery current
