GAMATRONIC ELECTRONIC INDUSTRIES LTD.
POWER
+
SA: 20, 30 and 40 kVA, Release 2.1
51
7.3 POWER
+
SA total shutdown (no ac output)
1. Switch the load OFF.
2. Press and hold the On/Off button for 10 seconds.
3. The control screen will indicate UPS OK (OFF).
LOAD LEVEL ---23:14:40---
L1:__________ 000A, 230V BATTERY: 864V
L2:__________ 000A, 230V UPS OK (OFF)
L3:__________ 000A, 230V STSW Warning !
Figure 62: Main screen – total shutdown
Figure 63: UPS off indication
