GAMATRONIC ELECTRONIC INDUSTRIES LTD.

POWER

SA: 20, 30, and 40 kVA, Release 2.1

9.10.2 Setting Battery Test Voltage Alarm

1. Select Test Alarm:

[Main Menu > SETUP > (password) > Battery]

1> Test-Voltage 5> Battery test…

2> Test Alarm 6> Capacity 0020 AH)

3> Current-Limit.. 7> ‘AuTo’ Test

4> Temp Compensat. 8> Enable/Dis Options

Figure 160: Battery setup menu

2. Using the arrow keys, set the battery test voltage alarm and press Ent:

[Main Menu > SETUP > (password) > Battery > Test Alarm]

BATTERY (TEST) VOLTAGE ALARM 360.0 V

Figure 161: Set battery test voltage alarm
