9.15.8 Setting the Menu Language
Select the desired menu language using the ▲▼ keys and press Ent:
[3-second Esc > Language]
----- LANGUAGE SETUP -----
SELECT - 1: English (selected)
SELECT - 2: Spanish
SELECT - 3: Portuguese
Figure 276: Set menu language
9.15.9 System Parameter Settings
User the arrow keys ▲▼ to select General, and then press Ent:
[3-second Esc]
1> UPSs Stat 5> Dry In/Out Stat
2> UPSs On/Off 6> Alarms Status
3> SoftWare Rev 7> Language
4> Network... 1 8> General
Figure 277: Select General
9.15.9.1 First General Screen
A description of the various system parameters shown in screen 1 are listed below.
[3-second Esc > GENERAL]
ACV:220...ALM:242/185 TEMP. ALARM:45C
MODULES:07/02 C.LIM= off , T.C= 2.0mV
DCV:432...ALM:475/360/340
BATT...TEST:04/05/360/352...CAP: 0010 AH
Figure 278: General (Screen 1)
a. ACV: nominal value of the input/output ac voltage (220 for 2x32 batteries; 110 for
2x16 batteries).
b. ALM: input ac voltage alarm HIGH/LOW.
c. TEMP. ALARM: high temperature limit for an external temperature sensor.
d. MODULES: QUANTITY/REDUNDANCY: 07/02 in the screen means that 7 modules
are presented in the system, 2 modules are reserve (full load is 10 kVA*(7-2)=50
kVA / 40 kW).
