GAMATRONIC ELECTRONIC INDUSTRIES LTD.
POWER
+
SA: 20, 30 and 40 kVA, Release 2.1
13
4. INSTALLATION
4.1 Installation Checklist
Complete the following checklist as you perform the installation, initialization, configuration,
and testing procedures. Refer to the appropriate sections (specified in the Reference
column) for detailed information about each checklist item.
When the checklist is complete, fax to Gamatronic at +972-2-582-8875.
Table 4: Installation checklist
POWER+ SA model and configuration
Customer Address
Site Phone E-mail
POWER+ SA Model
[ ] 20 kVA [ ] 30 kVA [ ] 40 kVA [ ] 3-phase
Technician Name Date Signature
√
Operation Requirement Reference
Visual Inspection
Verify the physical integrity of the system No physical damage
4.3.1
Verify that all components and modules are in
place
Components and modules are
securely fastened to shelves
4.3.1 Step 3
Comments on visual inspection: __________________________________________________
_______________________________________________________________________________
_______________________________________________________________________________
Site Preparation – Physical
Check ambient temperature
Recommend.: +15 °C and +25 °C
(+59 °F and +77
°F).
Min/Max: –10 °C and +40 °C
(+14 °F and +104
°F).
4.3.2 Step 1
Check humidity and condensation No condensation/dampness 4.3.2 Step 2
Check ventilation Proper airflow to batteries 4.3.2 Step 3
Check foundation and access Adequate structure and access 4.3.2 Step 4
Check for adequate clearances
91 cm (36 in.) at rear and 100 cm
(39 in.) at front
4.3.2 Step 5
Comments on site preparation – physical: __________________________________________
_______________________________________________________________________________
_______________________________________________________________________________
Site Preparation – Electrical
Check circuit breakers on electrical boards
supplying the P
OWER+ SA
Meet local code and Gamatronic
recommendations
4.3.3 Step 1
Check diameter of input and output power cables
connections, GND, and neutral lines
Meet local code and Gamatronic
recommendations
4.3.3 Step 2
Verify ac input voltages
Phase-to-Phase: 3x400 Vac,
±10 %
Phase-to-Neutral: 230 Vac, ±10 %
4.3.3 Step 3
Verify the voltage between neutral and ground 0–2 Vac 4.3.3 Step 4
