GAMATRONIC ELECTRONIC INDUSTRIES LTD.
POWER
+
SA: 20, 30 and 40 kVA, Release 2.1
85
9.9.5 Output Adjustment
1. Select Output Adjust:
[Main Menu > SETUP > (password) > Module conf.]
1. Num of phase 5.Output Adjust
2. Module/s frequency 6.Frequency Limits
3. Module/s voltage 7.DC Calibration
4. Update Vo/Fr/ph 8.AC Calibration
Figure 143: Module Config. setup menu
2. Select a phase to adjust and press Ent:
[Main Menu > SETUP > (password) > Module conf. > Output Adjust]
----- Select a phase to adjust -----
Select – 1: L1
Select – 2: L2
Select – 3: L3
Figure 144: Select a phase to adjust
3. Using the ▲▼ keys, select a module to adjust, and then Ent:
[Main Menu > SETUP > (password) > Module conf. > Output Adjust > Ent]
---- Select a module to adjust ----
01
---- Use Up/Down, Enter, or Esc. ----
Figure 145: Select a module to adjust
4. Using the ▲▼ keys select a value to adjust, and then press Ent:
[Main Menu > SETUP > (password) > Module conf. > Output Adjust > Ent > Ent]
------ Set a value to adjust ------
Phase: 1
00 Module: 01
---- Use Up/Down, Enter, or Esc. ----
Figure 146: Select a value to adjust
