9.11.4 Changing the Password

1. Select Password #1:

[Main Menu > SETUP > (password) > Ent]

1> Alarm set 5> Time 9> Silicon

2> Module conf. 6> Site

3> Battery 7> Password #1

4> Charge 8> Service

Figure 204: Setup menu

2. Use the arrow keys to change the password and press Ent, or press Esc to abort:

[Main Menu > SETUP > (password) > Password #1]

Change password

--------

Press Esc to abort

Figure 205: Change password
