3. Use the arrow keys to set the IP address, and then press Ent:

[Main Menu > SETUP > (password) > Ent > Service > SC2012 > Network > Set IP

ADDRESS]

Set IP ADDRESS

157.211.000.252

Figure 46: IP Address

4. Use the arrows keys to set the gateway and press Ent:

[Main Menu > SETUP > (password) > Ent > Service > SC2012 > Network > Set GATEWAY]

Set GATEWAY

157.211.000.251

Figure 47: Gateway

5. Select Store:

[Main Menu > SETUP > (password) > Ent > Service > SC2012 > Network]

1> Set IP ADDRESS 157.211.000.253

2> Set GATEWAY 157.211.000.251

3> Set MASK 255.255.255.000

4> Store 5> SNMP factor Select:1

Figure 48: Network menu

Entered information is now stored in the controller.
