GAMATRONIC ELECTRONIC INDUSTRIES LTD.
68
+
SA: 20, 30, and 40 kVA, Release 2.1
Table 11: Log Messages
# MESSAGE EXPLANATION
01 UPSMAJ More than 1 UPS Module is sending an alarm or fault warning
02 UPSMIN Single UPS Module is sending an alarm or fault warning
03 ------ N.A.
04 ------ N.A.
05 LOADBP
Load is now running on bypass. See Table 12 on page 69 to interpret
the LOADBP value.
06 VIBRA_
Alarm(s) vibrating. Alarm is frequently raised and lowered. Ignore to
avoid loading the log filling up.
07 OVTEMP Excess temperature
08 OUTFLT No ac output to load
09 BAT-HI Excessive battery voltage
10 ------ N.A.
11 BATEND End of battery backup. Battery is discharged to shutdown limit
12 BATLOW Low battery voltage
13 STSWRN Static Switch Warning or alarm
14 E.P.O. Emergency Power Off is active
15 EQ-HST
Battery is currently charging in equalizing mode, dc voltage is
temporarily increased
16 BATFLT Batteries failed last test
17 USER-1 User 1 input open
18 USER-2 User 2 input open
19 USER-3 User 3 input open
20 AC-BRN Input ac supply Brown Out
21 ACIN_H Ac input excessive
22 ACFAIL Ac input failure
23 STSWCM Static Switch does not respond
24 SLFFLT Last controller self-test failed
25 BAT-CB Battery Circuit Breaker Open
26 CURSHR
Current Sharing fault, load current is not equally divided between
modules
27 UPSOUT Fault (no current) in 1 or more output stage
28 UPSHDN UPS shutdown by EPO, Battery Discharge, ON/OFF pressed
29 OVLOAD Load current is high
30 UPS-CM One or more UPS’s not responding
31 STRTUP Startup time-stamp
32 ------ N.A.
Each message is formatted as follows:
Time – HH:MM:SS
Date – YY:MM:DD
