GAMATRONIC ELECTRONIC INDUSTRIES LTD.
80
POWER
+
SA: 20, 30, and 40 kVA, Release 2.1
4. Select UNDER TEMPERATURE:
[Main Menu > SETUP > (password) > ALARM SET > Temperature]
1> OVER TEMPERATURE
2> UNDER TEMPERATURE
PLEASE SELECT
Figure 129: Over/Under temperature menu
5. Use the arrow keys to set the battery minimum temperature alarm value, press Ent,
and then Esc:
[Main Menu > SETUP > (password) > ALARM SET > Temperature > UNDER
TEMPERATURE]
SET OVER TEMPERATURE ALARM VALUE
( 2 – 99) DEGREES
45
Figure 130: Set battery minimum temperature alarm
9.8.4 Setting Battery Integration Alarm
The Alarm Integration Factor determines the number of times that the controller polls and
retries to determine the UPS status before deciding on an error status. Setting the alarm
integration factor too low will cause spurious alarms to be generated; conversely, setting the
alarm integration factor too high may result in an alarm only being raised when it is already
too late to take corrective action.
1. Select INTEGRAT.:
[Main Menu > SETUP > (password) > ALARM SET]
1> AC VOLT 5> --------- 9>INTEGRAT.
2> FLOAT VOLT 6> ---------
3> --------- 7> TEMPERATURE
4> --------- 8> ---------
Figure 131: Alarm set menu
