2. View the input and output voltage and current for each phase of a particular UPS

module. Scroll down ▼ to view other UPS modules.

[Main Menu > UPS MODULE > ▼]

PHASE: -L1-- -L2-- -L3—

IN: 000V/000.0A 000V/000.0A 000V/000.0A

OUT: 000V/000.0A 000V/000.0A 000V/000.0A

UPS:# 01/04

Figure 92: Module phase voltages/currents

3. View the battery voltage for the selected UPS module (the parameters

I-ACTIVE and I-BUS are for a technician only).

[Main Menu > UPS MODULE > ▼ > ►]

BATT VOLT I-ACTIVE I- BUS

BATT+: 216V L1 000 L1 000

BATT-: 216V L2 000 L2 000

UPS: #01/04 L3 000 L3 000

Figure 93: Battery voltages & technician parameters
