VCI
Switched on/off VCI and select the desired thinkness (mm).
2D:SRI
Applies the filter to the rendered 2D image only.
Quality
This control improves the resolution by reducing the frame rate. Respectively it
reduces the resolution by increasing the image frame rate.
Vol. Angle
Adjusts the Volume Angle.
Mix
Adjusts value between the two selected render modes and gray threshold low of
3D images.
Save
Saves the preset.
B Mode Quality
Switches the B Mode Quality on/off
3D Rotate
Opens 3D Rotate menu.
Init
Sets all transitions and rotations back to the initial acquisition mode.
XL
Changes to wide format.
3D Orientation
Rotates the 3D image by selecting one of the two toggle buttons
The selected icon is shown in green.
Display formats
Selection of format controls.
The selected format is shown in green.
Gray/Tint Maps
Select the desired Gray/Tint map.
Probe Orientation
Opens the Probe Orientation menu.
Background
Adjusts the Background
Info 2D Param
Displays extended image information on the top right corner.
Orientation Help
Shows the planes orientation in the volume.
VCI Render Mode 1 (basic)
VCI Render Mode 2 (mix)
Select the desired Render Modes.
For more information see
' Render Modes '
on
page 8-27.
Gray Transparency
Adjusts the gray transparency.
Ref. Image
Ref. Image is able to be selected with the left trackball key. All image dependent functions like
parallel shifts, rotations, etc. are applied to the selected reference image.
Volume Cine Menu
For more information see
'Volume Cine'
on page 8-34.
8.7.3 OmniView
Note
OmniView is an option.
Obtain any plane from a 3D or 4D volume by simply drawing a line, curve, poly-line or trace
through a structure. This valuable technology enables views of even irregularly shaped
structures not attainable in 2D imaging.
Possible Acquisition Modes:
•
4D Real Time
•
3D Static
3D and 4D Mode
8-18
Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
5831612-100 R
evision 4
