Exam History:
•
direct access to images from previous exams
•
direct access to Measure Reports images from previous exams
•
Image compare window on screen to compare images from previous exams with
current exam image
Anonymize Archive
Fully anonymized Archive with own Patient ID
Harddrive data storage size:
about 450 GB
13.9.10 Connectivity
•
Ethernet network connection
•
USB for USB devices
•
WLAN network connection
•
DICOM support (option):
○
Verify
○
Print
○
Store
○
Modality Worklist
○
Structured Reporting
○
Storage Commitment
○
MPPS (Modality performed procedure step)
○
Media Exchange
○
Off network / mobile storage queue
○
Query/Retrieve
13.10 Scanning Parameters
13.10.1 B-Mode
Acc. power range: 1 - 100
Scan angle: changed in 5˚ increments (depends on used probe)
GAIN range: +15 to -25 dB
Frequency range: 1-18 MHz ( depending on the probe, 3 steps high, mid, low)
Frame rate >630 fps ( depending on the probe and application )
Gray scale values: 8 bit (256 gray values)
SRI 5 steps (1-5)
CRI 8 steps (1-8)
CRI filter 3 steps: off, low, high
Persistence filter: 8 steps (pre)
Line filter: 3 steps (pre) off, low (12,5/75/12,5%), high (25/50/25%)
Line density: 3 steps (pre) low, norm, high
Reject: 51 steps (pre) from 0 to 255
Enhance: 6 steps (0-5)
Gray maps: 18
Tint maps: 10
Dynamic: 12 different dynamic curves C1-C12
Technical Data/ Information
13-16
Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
5831612-100 R
evision 4
