OB Calculations
2D/3D Mode:
•
Biometry (Fetal Biometry, Early Gestation, Lung, Long Bones, Fetal Cranium,
AFI, Uterus, Ovary, Umbilical Vein, Uterine, EFW, Placenta, Cerebellar Vermis,
Cardiac Analysis)
•
Fetal Echo (Chambers, Thorax, Aorta/LVOT, Pulmonary/RVOT, Venous)
•
Z-Scores (Long Axis, Aortic Arch, Short Axis, Obi. Short Asix, 4 Chambers)
•
Nuchal Translucency
•
Intracranial Translucency
M Mode:
•
Biometry (Generic, FHR)
•
Fetal Echo (Chambers, Aorta/LVOT, Pulmonary/RVOT, FHR)
Doppler Mode:
•
Biometry (Ductus Art., Ao, Left/right Carotid, Left/Right MCA, Umbilical Art.,
SMA, Left/Right Uterine Art., FHR, Celiac Art., Left/Right UMA, IVC, Ovarian,
Umbilical Vein, MCA, Ductus Ven., LVOT Lt TEI, RVOT Rt TEI, PR intercal)
•
Fetal Echo (Mitral Vlave, Tricuspid Value, Aortic, Pulmonary,Pulm. Valve, LPA,
RPA, Ductus Art., Cardiac Output, FHR, RVOT Rt TEI, LVOT Lt TEI, Ductus
ven., Umbilical Vein, Pulmonary Veins, PR Interval)
TR Calculations
2D/3D Mode: Prostate
M Mode: no factory presets
Doppler Mode: no factory presets
Small Part Calculations
2D/3D Mode:
•
Small Parts (Thyroid Testice, Dor.Pen.A, Vessel)
•
Breast Lesion #1-5
M Mode: Vessel, Dor. Pen. A, Breast (Vessel)
Doppler Mode: Vessel, Dor. Pen. A., Breast (Vessel)
Cardio Calculations
2D/3D Mode: LV Simpson (Single & Bi-Plane), Volume A/L
(Volume Area/Length)
, LV-Mass (Epi
& Endo Area, LV Length), LV (RVD, IVS, LVD, LVPW), LVOT Diameter, RVOT
Diameter, MV (Dist A, Dist B, Area), TV (Diameter), AV/LA (Aortic Valve & Left
Atrium Diameter), PV (Diameter)
M Mode: LV, AV/LA, MV, HR
Doppler Mode: MV, AV, LVOT, TV, PV, RVOT, Pulmonary Veins, PAP, HR
ABDO Calculations
2D/3D Mode: Liver, Gallbladder, Pancreas, Spleen, Kidney, Renal Artery, Aorta, Vessel, Port. V.,
Bladder
M Mode: Renal Artery, Aorta , Vessel
Doppler Mode: Renal Artery, Aorta, Vessel, Portal Vein
Measurements and Calculations
10-14
Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
5831612-100 R
evision 4
