Note
2D JPEG Quality is only active when 2D Compression is set to JPEG.
Cine JPEG Quality is only active when Cine Compression is set to JPEG.
Volume Compr. Quality is only active when Volume Compr. is set to lossy.
If the volume contains color information, the color part of the volume is compressed with a
setting that is 5 points better than the selected setting, e.g. Setting Mid: color compression
High, grey compression Mid
If an image / multiframe cine is compressed using
lossy
JPEG compression, a yellow sign
(Jxx; xx = compression factor, e.g. JH) is added to the image (but not to secondary capture
images).
If a volume is compressed using
lossy
, a yellow sign (Wxx; xx = compression factor, e.g. W9)
is added when reloading the image.
Caution
A lossy compression can reduce image quality which can lead to a false diagnosis!
PRINT
Edit the
Printer Setup
as needed.
MPPS (Modality Performed Procedure Step)
Select the
Store Server
and the
SR Server
.
Only the images sent to the selected
Store Server
are added to the image list of the MPPS
completed (or discontinued) message.
Note
As soon as an MPPS server is created and selected, MPPS messages are created when an
exam is started or ended.
ST.COMMIT (Storage Commit)
Add a
ST.COMMIT
- Server. These servers can then be selected in the drop down list of the
STORE
-,
STORE3D
- and
STR.REPORT
- Service.
STR.REPORT (Structured Report)
With the DICOM Structured Report it is possible to send OB, GYN, Vascular and Cardio data.
Combine OB & GYN
If the checkbox is disabled, the system sends the OB- and GYN - data into one file.
If disable the files will be sent individually.
Include Scan Assistant Data
Select
yes
or
no
(default) from the dropdown menu.
Include Private Measure Data
Select
yes
(Retrieve trending data and the transfer of measure data in an private
format is enabled) or
no
(default) from the dropdown menu.
Note
DICOM Retrieval of measure data from past exams includes originally transferred data only. Any changes made after
transfer cannot be retrieved.
QR Server
Select an available Query Retrieve server from the dropdown menu to retrieve
measure data at a private format (necessary to retrieve trending data)
Private CSD Identifier
Select the CodingSchence Designator scheme for the transfer of DICOM SR data.
Available possibillities:
•
99GEK
•
GEK
•
Mixed (Used for old private tags (GEK), and newly entered private
tags(99GEK))
ViewPoint Default
Loads the default settings for ViewPoint.
System Setup
Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
5831612-100 R
evision 4 11-29
