13.2.2 Power Supply
Power requirements:
•
Protection class I
•
100 - 240 VAC
•
Frequency: 50 Hz, 60 Hz (± 2%)
Power consumption:
•
Max. 450VA including all options
•
Typical power consumption with ~400VA load approx. 1.75 A at 230V/50 Hz without
peripherals.
Thermal output: Max. 1370 BTU/h
Fan: Perceived noise level: max. 40 dB/A
Fuse:
•
Part number : 0034.1526
•
Technical spec:
○
Rated voltage : 250VAC
○
Rated Current : 10A
○
Breaking Capacity : 10A @250VAC
○
Operation speed : 40ms
13.2.3 AC Power Cord Set
Power cord: Type SJT, SJE, SJO or SJTO, 14AWG, 3-Conductor,VW-1, 125V, 15A or 250 V, 10 A, max 4.0
m long;
One end with Hospital Grade Type, NEMA 5-15P or 6-15P. Other end with appliance coupler.
"CAUTION Grounding reliability can only be achieved when the equipment is connected to an
equipment receptacle marked "Hospital Only" or "Hospital Grade"".
13.2.4 OPIO
OPIO:
•
Height adjustable:
○
Voluson SWIFT(18.5 inch) : 830mm ~ 1030mm
○
Voluson SWIFT+(21.5 inch) : 830mm ~ 1030mm
•
Rotation : Adjustable +/- 70° from center
Hard key buttons: Ergonomic layout, Interactive back-lightning
Recording keys: Integrated for remote control of up to 3 peripherals or DICOM devices, one dedicated
DVD recording key
13.2.5 Console Design
Probe ports:
•
3 active ports
•
Probe connection area designed to allow free movement of legs
Probe holder: 5
Solid State drive: Integrated SSD (Voluson SWIFT : 512 GB or 1TB, Voluson SWIFT+: 1TB)
Peripherals: On-board storage for peripherals: Black/white printer
Wheels: Wheel diameter 125mm, integrated locking mechanism that provides rolling lock
Cables: Integrated cable management
Handles: Rear handle
Technical Data/ Information
13-4
Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
5831612-100 R
evision 4
