13.9.8 2D CINE Features/Length
Cine Features:
•
Dual/Quad Image CINE Display
•
CINE Gauge and CINE Image number display
•
CINE Review Loop
•
Selectable CINE Sequence for CINE Review (by Start Frame and End Frame)
•
Side Change in dual CINE Mode
•
Measurements/Calculations & Annotations on CINE
Length:
•
512MB: up to 10 min. (depending on B-image size and FPS)
•
typical: about 3min/4000 images (with curved array: 15cm depth, angle 81˚, 22
FPS)
Cine operation:
•
manual: image by image
•
auto run: speed: 25 to 200% of real-time rate
•
play repeat mode: forward–forward, forward-backward-forward
13.9.9 Image/Volume Storage (Archive)
Image data stored as:
•
Raw data file (proprietary format)
•
DICOM file (Single- or Multiframe)
Volume file stored as:
•
Raw data file (proprietary format)
•
Size: typically: 0.8 - 5 MB (depending on probe and adjusted volume size)
Compression:
•
2D: JPEG, lossless, high, mid, low
•
3D/4D: Lossy and lossless compression available
Typical compression rates are 50% with lossless compression, 15% with lossy
compression but maximum quality and 5% with lossy compression and reduced
quality (approximate values).
Review:
•
Review of current Exam and archived data sets (Single Images and Cine Clips)
•
View Format: Raw data, DICOM data
•
Display Formats:1x1, 2x2, 3x3
Reload: Reload of current/ archived data sets:
•
2D Raw Data (incl. Color Doppler, Spectral Doppler and M-Mode)
•
3D Raw Data (Single Volume incl. Calc. Cines)
•
4D Raw Data (Volume Cine)
Export as:
•
Bitmap files: BMP, TIFF, JPEG
•
Raw files: RAW (2D), VOL (Volume data), 4DV (RAW, VOL incl. Patient data)
•
Sequence of Bitmaps: BMP,MP4
•
DICOM Files: DCM, DICOM Files with DICOMDIR
•
3D Raw Data: conversion to Cartesian format possible
AVI Codec: MS Video 1
Export to: DVD+R(W), CD-R(W), Network, USB devices, Email
Export Anonymous function: available for the following image types: BMP, TIFF, JPEG, MP4
Backup function to: DVD+ R(W) / CD-R(W), Network, USB devices
Repro function Settings recall (e.g. Geometry, Gain, Colormap, etc.) from a stored or reloaded picture
Technical Data/ Information
Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
5831612-100 R
evision 4 13-15
