Display modes: B, XTD
Screen formats:
•
2D imaging: Single (B), Dual (B+B), Quad (B+B+B+B)
•
XTD View: Single (XTD)
13.10.2 M-Mode
Working modes: M (conventional M-Mode) / AMM (Anatomical M-Mode)
Frequency range 1-18 MHz ( depending on the probe, 3 steps high, mid, low)
M Acoustic Power: 1 - 100
GAIN range: +15 to -25 dB
M sweep speeds:
•
900 / 450 / 300 / 225 / 150 / 100 pixels/sec.;
•
26.44 / 13.22 / 8.81 / 6.61 / 4.40 / 2.94 cm/s in relation to system monitor
Review (memory times): > 60 s (32MB)
Signal processing M:
•
Dynamic range: 1 to 12
•
Reject: 0 to 255
•
Enhance: 0 to 5
•
Gray maps: 18
•
Tint maps: 10
Display Modes:
•
M: 2D+M, 2D+M/CFM, 2D+M/HD-Flow™, 2D+M/PD
•
AMM: 2D+AMM, 2D/CFM+AMM/CFM, 2D/HD-Flow™+AMM/HD-Flow™
Screen formats:(window
arrangement)
•
2D+M and 2D+AMM: up/down (horizontal): three different sub formats 40/60,
50/50, 60/40%; left/right (vertical): 50/50%
•
2D+AMM+AMM: left//rt-up/rt-down: 50//25/25%
13.10.3 M-CFM-Mode
Acoustic MCFM Power 1-100
MCFM Color Maps 8 maps
Frequency range 1-18 MHz ( depending on the probe, 3 steps high, mid, low)
CFM Gain +/-15 dB range, 0.1 dB steps
CFM Velocity Scale Range PRF:100 Hz to 11 kHz
Wall Motion Filter 8 - 3000 Hz
Ensemble (color shots per
line)
8-16, step size 1
Gentle color filter
Smooth filter Rise: 12 steps
Fall: 12 steps
CFM Spectrum Inversion
CFM Baseline Shift 17 steps
Pre-settable and independently adjustable B-, M and MCFM Gain
CFM Threshold 1 - 255 steps
Balance 25 - 255, step size 5
Artifact suppression On/Off
Technical Data/ Information
Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
5831612-100 R
evision 4 13-17
