2. Click
Save&Return
to save the adjustments and return to the previous menu.
Compression Rate
Ultrasound images are consuming a lot of the system’s memory resources. Therefore, the
JPEG - compression method can be applied to the images to reduce their size. When
selecting a JPEG - compression less than 100% a message appears.
Note
Volume Wavelet Quality is only enabled if the volume compression is set to Wavelet Lossy.
If the volume contains color information, the color part of the volume is compressed with a
setting that is 5 points better than the selected setting, e.g. Setting Mid: color compression
High, grey compression Mid
If a volume is compressed using lossy wavelet compression, a yellow sign (Wxx; xx =
compression factor, e.g. W9) is added when reloading the image.
A lossy compression reduces image quality, which can lead to a false diagnosis!
11.2.3.3 Button Configuration
Figure 11-20 Button Configuration
The following buttons can be configured for performing specific functions:
•
P
•
Start Exam
•
End Exam
•
Freeze
11.2.3.3.1 P button
There are two different tabs available:
1.
Overview
: Select the basic actions to be performed when pressing a particular P - key.
2.
Detailed Setup
: Choose what exactly happens when a P - Key is pressed. (i.e.: If you
choose to save images in the
Overview
- tab, then the format of the images to save can
be selected in the
Detailed Setup
- tab.)
System Setup
11-34
Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
5831612-100 R
evision 4
