FC2250-UM-251-9370 7-59
7. DISASSEMBLY AND ADJUSTMENT
(7) Remove the M3L4 binding head screw holding the pen exible cable relay board.
M3L4 binding head screw
(8) Pull out the pen exible relay board from the Y slider.
(9) Disconnect the two Y exible cables from the pen ex relay board.
Y exible cable
Pen exible cable relay board
(10) Remove the two M3L6 binding head screws holding the right side of Y slider cover.
M3L6 binding head screw
Y slider cover
To Next Page
