GRAPHTEC FC2250 - Page 161

FC2250-UM-251-9370 9-5
9. TROUBLESHOOTING
Part 4
Is drawing
in plotter mode
normal?
The cut shape differs from
the specied shape.
No
Yes
Is the
interface setting
correct?
Set the interface on the
control panel.
Incorrect command selection
Specify the commands that
match the plotter.
Yes
Lower the cutting speed to
24 or lower.
No
