FC2250-UM-251-9370 9-4
9. TROUBLESHOOTING
Part 3
Is the
blade length too
long?
The blade skips over
certain parts of the medium.
The blade skips during
cutting.
No
Yes
Is the
blade chipped or
worn?
Replace with a new blade.
Is the
cutting speed high?
25 or more?
Set the blade length to
the thickness of the media
+0.1 mm.
Yes
Lower the cutting speed to
24 or lower.
There is a problem with
the medium. It is too hard.
No
No
Yes
Is the
acceleration high?
4 or more?
Lower the acceleration to 3
or less.
Yes
Is the
cutting force low?
9 or lower?
No
Raise the cutting force to
10 or more.
Yes
Is there
play in the mechanical
section?
No
Perform the necessary
adjustments.
Yes
No
Is there
unevenness in the
writing panel?
Replace the writing panel.
Yes
No
Is the pen
block installation
height correct?
Adjust the height using the
10.5 mm height adjustment
plate (standard accessory).
Yes
No
To Next Page
