43
Transmitter description - Telemetry data display
Speed display
0
km/h
If the corresponding sensor is available, this screen
displays the model’s actual speed over the ground.
Air pressure display
0.0
Bar
If the corresponding sensor is available, this screen
displays the actual air pressure.
“Weakest cell”
Cell0=0.00V
If the corresponding sensor is available, this screen dis-
plays the voltage of the weakest cell in a battery block,
together with the number of that cell.
ELECTRIC AIR MODUL
RX–S QUA: 100%
RX–S ST : 100%
TX–dBm: 33dBm
RX–dBm: 33dBm
RX–SPG.:4.8 TMP
V–PACK: 10ms
CH OUTPUT TYPE:ONCE
VARIO
GPS
RECEIVER
AIR ESC
GENERAL
ELECT. AIR
0.0V 0m/3s
BAT1 0m/1s
BAT2
0.0V T2 0°C
T1 0°C
0
1L0.00
2L0.00
3L0.00
4L0.00
5L0.00
6L0.00
ALT 0m
7L0.00
0.0V 0A
0.0V 0m/3s
BAT1 0m/1s
BAT2
0.0V T2 0°C
T1 0°C
0
1H0.00
2H0.00
3H0.00
4H0.00
5H0.00
6H0.00
ALT 0m
7H0.00
0.0V 0A
If attached to the receiver, this display will depict the
data acquired by an Electric-Air module, No. 33620.
More details about this module can be found in the
appendix or in Internet at www.graupner.de in the web
page for the given product.
Depending on how this module is equipped with sen-
sors, this screen can permanently display the data
shown in the adjacent table.
The current voltage of up to two batteries (BAT1 and
BAT2), up to two temperature measurements (T1 and
T2), current altitude with respect to the starting loca-
tion, the model’s ascent/decent rate in m/1 s and m/3 s
and, in the middle of the screen, the current draw cur-
rently being taken from a power source.
In the centre including the current level relative to the
location and the climb / descent of the model in m /
1s and m / 3 s and the left of it connected by possibly
the module temperature / voltage sensors (No. 33612
or 33613) possibly measured current voltages of up
to two battery packs (and BAT1 BAT2). In the middle
below the corresponding temperatures.
Along the right edge of the screen is a table of alternat-
ing values for cell voltages at balancer connections (L)
or voltages for up to 7 attached battery cell packs (H).
The displayed items are as follows:
Value Explanation
ON Current control ON
V current voltage
A current current
BAT1 /
BAT2
battery 1 or 2
ALT current altitude
m/1s m/1 s ascent/decent rate
m/3s m/3 s ascent/decent rate
100
Signal quality in % (RX-S QUA)
T1 / T2 temperature of sensor 1 or 2
L or H cell voltage of cells 1 … max. 14
L = balancer connection 1
H = balancer connection 2
