Transmitter description - Telemetry data display
Micro-copter display
0mAh
0:00
0.0V
0km/h
0
I:
Dir:
Alt: 0m
0°
0A
0m
0°
This screen displays the data generated by a HoTT-
compatible micro-copter. Key, reading from top left to
bottom right:
Value Explanation
V Actual voltage
“0:00“ Period switched on
mAh Battery capacity consumed
“0“ Position number of the satellites
km/h Speed over ground, according to GPS
system
Alt Actual altitude
Dir Direction of movement
I Actual current
m Distance from take-off point, according
to GPS system
° Position in degrees relative to take-off
point, according to GPS system
Any messages from the micro-copter sensor are dis-
played in the bottom line of the screen, which is empty
in the screen-shot shown above.
ACCU
0.0V
0.0A
0mAh
This display depicts current voltage, current current
draw and, if attached, the expended capacity of “Batt
1” connected to the Electric-Air module (No.33620).
SENSOR 1
0.0V
0°C
SENSOR 1
If attached, this display depicts currently measured
voltage and temperature from a temperature/voltage
sensor (No. 33612 or 33613) connected to “T(EMP)1”
of the Electric-Air module (No.33620).
SENSOR 2
0.0V
0°C
SENSOR 2
If attached, this display depicts currently measured
voltage and temperature from a temperature/voltage
sensor (No. 33612 or 33613) connected to “T(EMP)2”
of the Electric-Air module (No.33620).
Vario
m
m
s
If attached, this display will depict the altitude (in m)
relative to location, starting location as well as the
current rate of ascent/descent (in m/s) data origina ting
from a Vario integrated into a Electric-Airmodule (No.
33620).
Speed display
0
km/h
If the corresponding sensor is available, this screen
displays the model’s actual speed over the ground.
“Weakest cell”
Cell0=0.00V
If the corresponding sensor is available, this screen dis-
plays the voltage of the weakest cell in a battery block,
together with the number of that cell.
To Next Page
