4. Remove the oil seal and inner bearing
a. Use the screwdriver to pry out the oil seal
b. Remove the inner race of inner bearing form the hub.
Check and repair of front hub
1. Check all bearings
Wash the inner race and outer race of each bearing and check them for
wear and damage.
2. Replace the bearing outer race
a. Use the brass bar and hand hammer to knock out the bearing outer
race.
Use the special tools to knock in the new bearing outer race.
Assembly of front hub
1. Coat the inner surface of hub and bearing outer race
with the grease.
The grease is the Jin HP-R grease or the grease met the requirement
in following table.
special
tools
diagram of
special tools
grease
Dropping point, C
Leakage amount (104 C, 6h), g
EP performance OK value , N
Item
Typical data
