Installation of ball pin
1. Install the upper ball pin on the upper arm
Tightening force: 78 5N m
2. Install the lower ball pin on the lower arm
Tightening force: 140 10N m
3. Install the steering knuckle and front hub assembly
(Refer to section “Front Hub and Steering Knuckle”)
