Replacement of upper arm bush
1. Remove the bush
a. Remove the bolt and washer.
b. Use the special tools to push out the bush.
c. Remove the upper arm shaft; remove another bush in same
procedure.
2. Install the bush
a. Use the special tools to press in the bush.
b. Install the upper arm shaft; use the special tools to press in
another bush.
3. Tighten the upper arm shaft to specified torque.
a. Coat the screw of both ends of upper arm shaft with the
screw lock sealant; install the washer and nut.
Remarks: Adjust the position of upper lower; make the
installation plane of ball pin is vertical to the installation
plane of upper arm shaft.
special
special
special
