31.Use the special tools to install the needle bearing in
the major semiaxle.
32.Use the special tools to install the major semiaxle
bearing by press..
33. Use the circlip pliers to install the circlip to clamp
the bearing inner race of major semiaxle.
34.Insert the spline on small end of major semiaxle
into the spline of front reducer half axle gear; use
the brass rod and hand hammer to knock the major
semiaxle into the front reducer.
Caution: Does not damage the inside needle bearing.
On spline of large end of major semiaxle when
knock in the major semiaxle.
35.Use the circlip pliers to install the circlip in the
flange and clamp the major semiaxle bearing outer
race.
36. Push the mechanical wheel of separator into
theneedle bearing inner race in major semiaxle until
can not move.
special tools
special tools
special tools
