CD Player and Air Conditioning System-8
Step 6: Display “06”(set the temperature zone)
Press down “Temp+” switch
Display the detection code of mode/
temperature damper executor
Press down “Temp+” switch
Step 7: display
“07”(set the temperature zone)
Action of the executor mechanism
:
Mode damper: wind to the person
Circulation damper: internal circulation
Temperature damper: cold end
Wind amount: the maximum
Compressor: enabled
Note: X is a digital number without specific meaning; the code
number is displayed in the outside temperature display zone.
display
“08”
C
Code number
Code Meaning
0x0
Temperature damper executor works normally
0x1
Detection for temperature damper executor is in progress.
0x2
Temperature damper executor failure
00x
Mode damper executor works normally
01x
Detection for mode damper executor is in progress.
02x
Mode damper executor failure
