Appendix A-3
1. (upper suspension arm steering knuckle ball pin nut) bolt
Locate the rear transverse stabilizer rob in the corresponding
position of carriage, symmetries the left and right during
installation.
Connection of rear transverse
stabilizer rod and rear axle
Viewing confirmation
the fixed torque of nut 2 in the Figure is 23
3N m
Torque wrench
Connection of rear transverse
stabilizer rod and rear transverse
stabilizer robs connecting bar
assembly.
the fixed torque of nut 1 in the Figure is 63
5N m
Torque wrench
rear transverse stabilizer
rear transverse stabilizer rod connecting bar assembly
bush
Upper suspension arm and upper suspension
arm steering knuckle ball pin
Steering gear cross tie ball pin
Lower suspension arm and lower suspension
arm steering knuckle ball pin
the fixed torque of nut 1 in the Figure is
145
15N m
the fixed torque of nut 2 in the Figure is120
10N m
the fixed torque of nut 3 in the Figure is 230
20N m
Torque wrench
Torque wrench
Torque wrench
2. (steering gear cross tie ball pin nut) left steering
knuckle and wheel hub brake assembly
3. (lower suspension arm steering knuckle ball pin nut bolt
4. left steering knuckle and steering knuckle
and wheel hub brake assembly.
