Appendix A-8
front windshield glass
Apply washer on the front windshield
glass-sticking region
Evenly apply it on the sticking region with the width of about
25mm and completely volatilize it.
Viewing confirmation
Viewing confirmation
Apply base-coater on the front
windshield glass-sticking region
Shake the base-coater to be sufficiently even followed by the
even application on the sticking region with the width of about
20mm and dry it for 2-15 minutes
Apply washer on front windshield
glass
Wash the glass frame with the width of about 25mm,
instantly clean it and volatilize the washer completely.
Apply adhesive on front windshield
glass
Shake the glass base-coater to be sufficiently even followed
by the even application on the glass frame with the width of
about 20 and dry it for 2-15 minutes
Apply base-coater on front
windshield glass
Vertically apply the glass adhesive on the glass frame and
make it even and continuous. Height: 18mm, width: 12mm
Front windshield glass fixing
Instantly install and fix the glass after the glass adhesive
application. Set the left and right clearance between front
windshield glass and the glass frame to be 12mm
Viewing confirmation
Viewing confirmation
Viewing confirmation
Viewing confirmation
Wash, base-coat and stick according to the corresponding positions showed by the broken line in the Figure
